| Applicable Profiles | Flat steel, angle iron, channel steel, strip steel, round steel |
| Max. Machining Thickness | Flat steel ≤ 60 mm (heavy-duty models up to 70 mm) |
| Max. Machining Width | Flat steel ≤ 140 mm |
| Min. Bending Diameter | Φ180–Φ300 mm (varies by profile specification) |
| Max. Bending Diameter | Φ6000 mm (customizable for larger sizes) |
| Drive Type | Full hydraulic drive (three-roll structure, upper roll down-pressing) |
| Forming Precision | Roundness error ≤ ±0.5 mm |
| Forming Speed | Approx. 2–3 m/min |
| Motor Power | 7.5–15 kW (varies by model size) |
| Hydraulic System Pressure | 16–25 MPa |
| Control Mode | Digital/CNC control with diameter parameter setting |
| Applicable Materials | Carbon steel, stainless steel, alloy steel, etc. |
| Overall Dimensions (Reference) | Approx. 2800×1250×1300 mm (L×W×H, varies by model) |
| Machine Weight | Approx. 2–5 tons |
